Installing the August Doorbell Cam Pro is simpler than you think—this guide walks you through every step, from checking compatibility to final testing. With clear instructions and helpful tips, you’ll have your smart doorbell up and running in under an hour.
Key Takeaways
- Check compatibility first: Ensure your existing doorbell wiring and transformer meet the 16–24V AC requirement before installation.
- Turn off power at the breaker: Safety is critical—always shut off electricity to the doorbell circuit before starting.
- Use the August app for setup: The app guides you through Wi-Fi connection, motion zones, and notification preferences.
- Secure mounting is essential: Attach the doorbell firmly to prevent wobbling, which can affect video quality and motion detection.
- Test after installation: Verify live view, two-way audio, and motion alerts work properly before finishing.
- Troubleshoot common issues: If the doorbell doesn’t power on or connect, check wiring, Wi-Fi signal, and app settings.
- Consider a chime connector: If your mechanical chime doesn’t work, the August Chime Connector ensures compatibility.
How to Install August Doorbell Cam Pro
So, you’ve decided to upgrade your home security with the August Doorbell Cam Pro. Great choice! This sleek, feature-packed smart doorbell offers HD video, two-way audio, motion detection, and seamless integration with your smartphone. But before you can enjoy those crisp nighttime recordings and instant alerts, you need to install it properly.
Don’t worry—this guide will walk you through the entire process, from checking your doorbell’s compatibility to testing the final setup. Whether you’re a DIY enthusiast or a first-time installer, we’ve got you covered. By the end of this guide, you’ll have your August Doorbell Cam Pro securely mounted, connected to Wi-Fi, and ready to keep an eye on your front door.
Let’s get started.
What You’ll Need Before You Begin
Visual guide about How to Install August Doorbell Cam Pro
Image source: cdn2.bigcommerce.com
Before diving into the installation, make sure you have all the necessary tools and materials. Having everything ready will save time and prevent frustration.
You’ll need:
– August Doorbell Cam Pro (obviously!)
– Smartphone with the August app installed (iOS or Android)
– Screwdriver (usually Phillips head)
– Drill and drill bits (if mounting on brick, stucco, or concrete)
– Voltage tester (optional but recommended)
– Ladder (if your doorbell is high up)
– Wire strippers (if you need to trim or re-strip wires)
– Masking tape or wire labels (to keep track of wires)
Also, ensure your home meets the basic requirements:
– Existing doorbell wiring (two wires: front and transformer)
– A working doorbell transformer that outputs 16–24 volts AC
– Strong Wi-Fi signal at the doorbell location (2.4 GHz network recommended)
– A compatible mechanical or digital chime (or use the August Chime Connector if needed)
If you’re unsure about your transformer voltage, check the label near your chime or contact an electrician. Installing a doorbell with insufficient power can cause malfunctions or damage the device.
Step 1: Turn Off the Power
Safety first! Even though doorbell wires carry low voltage, it’s still important to turn off the power before handling them.
Locate Your Circuit Breaker
Go to your home’s main electrical panel (usually in the basement, garage, or utility closet). Look for the breaker labeled “doorbell,” “chime,” or something similar. If there’s no label, you may need to test each breaker by turning them off one at a time and checking if your existing doorbell stops working.
Turn Off the Breaker
Once you’ve identified the correct breaker, switch it to the “off” position. Use a non-contact voltage tester near the doorbell wires to confirm there’s no power. Simply touch the tester to the wires—if it doesn’t beep or light up, you’re safe to proceed.
Pro tip: Place a piece of tape over the breaker switch so no one accidentally turns it back on while you’re working.
Step 2: Remove Your Old Doorbell
Now that the power is off, it’s time to remove your existing doorbell.
Unscrew the Faceplate
Use your screwdriver to remove the screws holding the old doorbell to the wall. Gently pull the doorbell away from the wall—don’t yank it, as the wires are still connected.
Disconnect the Wires
You’ll see two wires attached to the back of the doorbell (usually labeled “Front” and “Trans”). Loosen the screws or release the clips holding the wires in place. Carefully pull the wires free.
Label the wires with tape or remember which is which—this will help during reinstallation. The August Doorbell Cam Pro doesn’t require polarity, but it’s still good practice to keep track.
Cap the Wires (Optional)
If you’re not installing the new doorbell immediately, twist wire nuts over the exposed ends to prevent short circuits. Store them safely inside the wall or junction box.
Step 3: Check Compatibility and Prepare the Mounting Location
Before mounting the August Doorbell Cam Pro, make sure your setup is compatible.
Verify Voltage
Use a multimeter to check the voltage across the two doorbell wires. Set the meter to AC voltage and touch the probes to each wire. You should see a reading between 16 and 24 volts. If it’s below 16V, your transformer may be too weak, and the doorbell might not work reliably.
Assess Wi-Fi Signal
Stand at the doorbell location with your phone and check the Wi-Fi signal strength. The August Doorbell Cam Pro requires a stable 2.4 GHz connection. If the signal is weak, consider installing a Wi-Fi extender or moving your router closer.
Clear the Mounting Area
Clean the wall surface where you’ll mount the doorbell. Remove dirt, paint flakes, or old adhesive. If you’re mounting on brick or stucco, you’ll need a drill to create pilot holes.
Step 4: Install the Mounting Bracket
The August Doorbell Cam Pro comes with a universal mounting bracket that fits most doorbell locations.
Position the Bracket
Hold the bracket against the wall where you removed the old doorbell. Make sure it’s level—use a spirit level if needed. The bracket has slotted holes, allowing for slight adjustments.
Mark the Screw Holes
Use a pencil to mark the spots where you’ll drill. If you’re mounting on wood or drywall, you can screw directly into the surface. For brick, concrete, or stucco, drill pilot holes and use wall anchors.
Secure the Bracket
Attach the bracket using the provided screws. Make sure it’s tight and doesn’t wobble. A loose bracket can cause the camera to tilt or vibrate, affecting video quality.
Route the Wires
Feed the two doorbell wires through the center hole of the bracket. Leave enough slack so you can easily connect them to the August Doorbell Cam Pro.
Step 5: Connect the Wires to the Doorbell
Now it’s time to connect your doorbell wires to the August Doorbell Cam Pro.
Identify the Terminals
On the back of the August Doorbell Cam Pro, you’ll see two small terminals labeled “Front” and “Trans.” These correspond to your existing doorbell wires.
Strip the Wire Ends (If Needed)
If the wire ends are frayed or too short, use wire strippers to expose about 1/4 inch of copper. Be careful not to cut too much insulation.
Attach the Wires
Loosen the terminal screws slightly. Insert one wire into the “Front” terminal and the other into the “Trans” terminal. Tighten the screws to secure the connections. The August Doorbell Cam Pro is designed to work regardless of wire polarity, so don’t worry about which wire goes where.
Pro tip: If the wires are too short or damaged, you can splice in new wire using wire nuts and electrical tape. Just make sure the connections are secure and insulated.
Step 6: Attach the Doorbell to the Bracket
With the wires connected, it’s time to mount the doorbell.
Align the Doorbell
Hold the August Doorbell Cam Pro against the bracket. The bottom of the doorbell should snap into place, while the top attaches with a screw.
Secure with the Security Screw
Use the provided security screw and screwdriver to fasten the top of the doorbell to the bracket. This prevents theft and ensures a stable connection.
Double-Check Connections
Give the doorbell a gentle tug to make sure it’s firmly attached. Wiggle the wires slightly to confirm they’re secure and not pulling loose.
Step 7: Turn the Power Back On
Now that everything is connected, it’s time to restore power.
Flip the Breaker
Return to your electrical panel and switch the doorbell breaker back to the “on” position.
Wait for the Doorbell to Power Up
The August Doorbell Cam Pro will take a few seconds to boot up. You’ll see a light ring on the front—this indicates it’s receiving power and initializing.
If the light doesn’t turn on, double-check your wiring and breaker. If the issue persists, refer to the troubleshooting section below.
Step 8: Set Up the August Doorbell Cam Pro Using the App
The August app is your control center for the doorbell. Download it from the App Store or Google Play if you haven’t already.
Create or Log In to Your August Account
Open the app and sign in with your existing August account or create a new one. You’ll need an email address and password.
Add a New Device
Tap the “+” icon in the app and select “Doorbell Cam Pro.” Follow the on-screen prompts.
Scan the QR Code
The app will ask you to scan the QR code on the back of the doorbell. Hold your phone steady until it recognizes the code.
Connect to Wi-Fi
Select your home Wi-Fi network and enter the password. The doorbell only supports 2.4 GHz networks—make sure you’re not trying to connect to a 5 GHz band.
Configure Settings
Once connected, the app will guide you through setup:
– Set motion zones (choose areas where you want alerts)
– Adjust motion sensitivity
– Enable or disable chime notifications
– Set up two-way audio preferences
– Choose notification schedules (e.g., only during certain hours)
You can also link the doorbell to other August smart locks or home automation systems for a fully integrated experience.
Step 9: Test the Doorbell
Before calling the job done, test all features to ensure everything works.
Check Live View
Open the August app and tap “Live View.” You should see a clear, real-time video feed from your doorbell. Move around to test the field of view.
Test Two-Way Audio
Tap the microphone icon and speak. You should hear your voice through the doorbell’s speaker. Have someone stand outside and test the audio from their end.
Trigger Motion Alerts
Walk in front of the doorbell to trigger motion detection. You should receive a push notification on your phone within a few seconds.
Ring the Doorbell
Press the button on the doorbell. Your chime should sound, and you should receive a notification. If your chime doesn’t work, you may need the August Chime Connector (see troubleshooting).
Troubleshooting Common Installation Issues
Even with careful installation, problems can arise. Here’s how to fix the most common issues.
Doorbell Won’t Power On
– Check that the breaker is on.
– Verify wire connections are tight and not reversed.
– Test voltage with a multimeter—should be 16–24V AC.
– Ensure the transformer is functioning.
Wi-Fi Connection Fails
– Make sure you’re using a 2.4 GHz network.
– Move your router closer or use a Wi-Fi extender.
– Restart your router and the doorbell.
– Re-enter the Wi-Fi password carefully.
Chime Doesn’t Ring
– If you have a mechanical chime, it may not be compatible. Use the August Chime Connector (sold separately).
– For digital chimes, check compatibility on the August website.
– Ensure the chime wires are connected properly at the chime unit.
Video Quality Is Poor
– Clean the camera lens with a soft, dry cloth.
– Check for obstructions (e.g., dirt, spider webs).
– Ensure strong Wi-Fi signal—low bandwidth can cause lag or pixelation.
Motion Alerts Not Working
– Adjust motion sensitivity in the app.
– Make sure motion zones are set correctly.
– Ensure the doorbell is not facing direct sunlight or heat sources, which can trigger false alerts.
Maintenance and Care Tips
To keep your August Doorbell Cam Pro working smoothly, follow these maintenance tips:
– Clean the lens monthly with a microfiber cloth.
– Check for firmware updates in the August app—these improve performance and security.
– Inspect wires and connections annually, especially after storms or extreme weather.
– Replace the battery (if using battery mode) every 6–12 months, though the wired version doesn’t require this.
Conclusion
Installing the August Doorbell Cam Pro is a straightforward process that enhances your home’s security and convenience. By following this step-by-step guide—checking compatibility, turning off power, mounting the bracket, connecting wires, and setting up the app—you can complete the installation in under an hour.
Remember, safety is key: always turn off the breaker before handling wires. And don’t skip the testing phase—verifying live view, audio, and alerts ensures everything works as expected.
With your new smart doorbell in place, you’ll enjoy peace of mind knowing you can see and speak to visitors from anywhere. Whether you’re at work, on vacation, or just relaxing on the couch, the August Doorbell Cam Pro keeps you connected to your front door.
So go ahead—mount that doorbell, connect to Wi-Fi, and start enjoying the benefits of smart home security today.
