Installing the Ring Doorbell Pro with Chime is easier than you think—even if you’re not a tech expert. This guide walks you through every step, from checking your doorbell wiring to syncing your new smart doorbell with the Ring app and Chime device for reliable alerts.
Key Takeaways
- Check your existing doorbell wiring: The Ring Doorbell Pro requires a wired connection with 16–24V AC power to function properly.
- Use the Ring Chime for enhanced alerts: The Chime plugs into a standard outlet and plays customizable sounds when someone rings your doorbell or triggers motion.
- Install the Pro Power Kit: This small device connects to your chime box to ensure consistent power delivery to your Ring Doorbell Pro.
- Download the Ring app: Essential for setup, live view, motion detection settings, and receiving notifications on your phone.
- Follow safety precautions: Always turn off power at the breaker before working with electrical wiring to avoid shocks or damage.
- Test after installation: Verify video quality, motion detection, and Chime alerts before finishing the setup.
- Troubleshoot common issues: Problems like no power, poor Wi-Fi, or silent Chime can usually be fixed with simple steps in the app or hardware checks.
How to Install Ring Doorbell Pro with Chime
So, you’ve decided to upgrade your home security with the Ring Doorbell Pro and want to pair it with the Ring Chime for loud, customizable alerts. Great choice! The Ring Doorbell Pro offers 1080p HD video, advanced motion detection, two-way talk, and professional-grade security features—all powered by your existing doorbell wiring. And when you add the Ring Chime, you’ll get audible alerts even if your phone is on silent or in another room.
In this complete guide, we’ll walk you through every step of installing your Ring Doorbell Pro with Chime—from checking your current doorbell setup to final testing and troubleshooting. Whether you’re a DIY beginner or a seasoned home improver, this guide is designed to be clear, safe, and easy to follow. By the end, you’ll have a fully functional smart doorbell system that keeps you connected and your home secure.
Let’s get started!
What You’ll Need Before You Begin
Visual guide about How to Install Ring Doorbell Pro with Chime
Image source: storage.googleapis.com
Before you touch a single wire, make sure you have all the tools and components ready. Rushing this step can lead to frustration or even damage to your doorbell system.
Here’s a checklist of what you’ll need:
- Ring Doorbell Pro – The main device that replaces your old doorbell button.
- Ring Chime or Chime Pro – Plugs into a wall outlet and plays alerts when the doorbell is pressed or motion is detected.
- Ring Pro Power Kit – A small transformer-like device that connects inside your chime box to ensure stable power delivery.
- Screwdriver set – Typically a Phillips head and flathead for removing covers and securing wires.
- Drill and drill bits (optional) – Only if you need to create new mounting holes or run wires.
- Voltage tester (recommended) – To confirm your doorbell transformer is outputting the correct voltage (16–24V AC).
- Smartphone or tablet – With the Ring app installed (available on iOS and Android).
- Wi-Fi network – Your home Wi-Fi must support 2.4 GHz (Ring Doorbell Pro does not support 5 GHz only networks).
- Ladder (if needed) – For reaching high doorbell locations.
Having everything ready will make the installation smoother and safer.
Step 1: Turn Off Power at the Breaker
Safety first! Even though doorbell circuits are low voltage, they’re still connected to your home’s electrical system. Working on live wires can damage your Ring Doorbell Pro or cause injury.
Locate Your Electrical Panel
Go to your home’s main electrical panel (breaker box). Look for the circuit labeled “doorbell,” “chime,” or something similar. If you can’t find a labeled breaker, you may need to test each one by turning them off and checking if your existing doorbell stops working.
Turn Off the Correct Breaker
Switch off the breaker that controls your doorbell circuit. Use a non-contact voltage tester at the doorbell or chime box to confirm power is off. If the tester doesn’t light up, you’re safe to proceed.
Pro Tip: Take a photo of your breaker panel before turning anything off. This helps you remember which breaker controls what when you turn the power back on.
Step 2: Remove Your Existing Doorbell Button
Now that the power is off, it’s time to remove your old doorbell button.
Unscrew the Faceplate
Use a screwdriver to remove the screws holding your current doorbell button to the wall. Gently pull the button away from the wall to expose the wires behind it.
Disconnect the Wires
You’ll see two wires connected to the back of the button—usually labeled “Front” and “Trans” or just two bare copper wires. Loosen the screws holding these wires and carefully remove them. Don’t let the wires fall back into the wall!
Important: Take a photo of the wiring before disconnecting. This helps you remember how to reconnect them later.
Cap the Wires (Temporarily)
Use wire nuts or electrical tape to cover the exposed ends of the wires. This prevents accidental contact while you work.
Step 3: Check Your Doorbell Transformer Voltage
The Ring Doorbell Pro requires a transformer that outputs between 16 and 24 volts AC. If your current transformer is too weak (below 16V), your Ring Doorbell Pro may not work properly or could overheat.
Locate Your Doorbell Transformer
The transformer is usually found in your basement, garage, or near your electrical panel. It’s a small black box with wires leading to your doorbell and chime.
Test the Voltage
Use a multimeter or voltage tester to check the output. Set your meter to AC voltage and touch the probes to the two wires coming from the transformer. If it reads between 16–24V, you’re good to go. If it’s below 16V, you may need to upgrade your transformer.
Note: If you’re unsure about testing voltage, consult an electrician. Using an underpowered transformer can damage your Ring device.
Step 4: Install the Ring Pro Power Kit
The Ring Pro Power Kit is a small but crucial component. It ensures your Ring Doorbell Pro gets consistent power, especially if your existing chime is mechanical (not digital).
Locate Your Chime Box
This is usually inside your home, near the front door. Open the cover to access the wiring.
Disconnect the “Front” Wire
Find the wire labeled “Front” (connected to your doorbell button). Disconnect it from the chime terminal.
Connect the Pro Power Kit
The Pro Power Kit has two wires: one red and one black. Connect the red wire to the “Front” terminal on the chime. Connect the black wire to the other terminal (usually “Trans” or “Common”).
Secure the Kit
Mount the Pro Power Kit inside the chime box using the included adhesive pad or screws. Make sure it doesn’t touch any metal parts.
Reconnect the Doorbell Wires
Now, connect the two wires from your doorbell button location to the Pro Power Kit’s terminal block. It doesn’t matter which wire goes where—just make sure they’re secure.
Pro Tip: Label the wires if you’re worried about mixing them up. But remember, polarity doesn’t matter with AC doorbell circuits.
Step 5: Mount the Ring Doorbell Pro
Now it’s time to install the Ring Doorbell Pro at your door.
Position the Mounting Bracket
Hold the mounting bracket against the wall where you want the doorbell. Make sure it’s level and at a comfortable height (typically 48 inches from the ground).
Mark the Screw Holes
Use a pencil to mark where the screws will go. If you’re drilling into brick or concrete, use a masonry bit and wall anchors.
Drill and Secure the Bracket
Drill pilot holes if needed, then screw the bracket into place using the provided screws.
Connect the Wires
Thread the two doorbell wires through the center hole of the bracket. Then, connect them to the terminals on the back of the Ring Doorbell Pro. Again, polarity doesn’t matter—just ensure a tight connection.
Attach the Doorbell
Slide the Ring Doorbell Pro onto the mounting bracket until it clicks into place. Secure it with the included security screw using the provided screwdriver.
Note: The Ring Doorbell Pro comes with a wedge kit if you need to angle it for better coverage. Use it if your door is recessed or you want to reduce glare.
Step 6: Set Up the Ring Chime
The Ring Chime is what gives you audible alerts inside your home. It’s simple to set up and highly customizable.
Plug in the Chime
Find a standard wall outlet near your front door or in a central location. Plug in the Ring Chime. It will light up and begin pairing mode.
Download and Open the Ring App
If you haven’t already, download the Ring app from the App Store or Google Play. Create an account or log in.
Add the Chime to the App
In the app, tap the three-line menu, then select “Set Up a Device.” Choose “Chime” and follow the on-screen instructions. The app will guide you through connecting the Chime to your Wi-Fi network.
Customize Your Chime Sound
Once connected, you can choose from over 40 different sounds, adjust the volume, and set quiet hours. You can also link multiple Chimes to play in sync.
Pro Tip: Use the Chime Pro if you have a large home or weak Wi-Fi. It acts as a Wi-Fi extender and boosts your Ring device’s signal.
Step 7: Connect the Ring Doorbell Pro to the App
Now it’s time to bring your doorbell online.
Turn Power Back On
Go back to your breaker panel and turn the doorbell circuit back on. Wait about 30 seconds for the Ring Doorbell Pro to power up.
Open the Ring App
Tap “Set Up a Device” and select “Doorbells.” Choose “Ring Doorbell Pro.”
Scan the QR Code
Use your phone’s camera to scan the QR code on the back of the doorbell or inside the app. This links the device to your account.
Connect to Wi-Fi
Follow the prompts to connect your doorbell to your 2.4 GHz Wi-Fi network. Enter your password when prompted.
Complete the Setup
The app will guide you through naming your doorbell, setting motion zones, enabling notifications, and testing the live view.
Note: If the doorbell doesn’t connect, try moving closer to your router or using the Chime Pro to extend the signal.
Step 8: Test Your Installation
Before you call it a day, make sure everything works as expected.
Test the Doorbell
Press the button on your Ring Doorbell Pro. You should hear the chime inside your home and receive a notification on your phone.
Check Live View
Open the Ring app and tap “Live View.” You should see a clear video feed from your doorbell. Test the two-way talk feature by speaking through the app.
Test Motion Detection
Walk in front of the doorbell to trigger motion alerts. Adjust the motion zones in the app if needed to avoid false alarms from passing cars or trees.
Test the Chime
Make sure the Chime plays the correct sound at the right volume. Try different sounds to find your favorite.
Pro Tip: Invite family members to the app so they can also receive alerts and view the camera.
Troubleshooting Common Issues
Even with careful installation, you might run into a few hiccups. Here’s how to fix the most common problems.
Doorbell Won’t Power On
- Double-check that the breaker is on.
- Verify the transformer voltage is 16–24V AC.
- Ensure the Pro Power Kit is installed correctly in the chime box.
- Check that wires are securely connected and not loose.
No Video or Poor Video Quality
- Make sure your Wi-Fi signal is strong at the doorbell location.
- Use the Chime Pro to extend Wi-Fi range.
- Clean the camera lens with a soft cloth.
- Adjust the angle to reduce glare from sunlight.
Chime Doesn’t Ring
- Confirm the Chime is plugged in and connected to Wi-Fi.
- Check that it’s linked to the correct doorbell in the app.
- Ensure the volume is turned up and not in quiet mode.
- Restart the Chime by unplugging it for 10 seconds.
Motion Alerts Not Working
- Enable motion detection in the app.
- Adjust motion zones to cover the desired area.
- Make sure the doorbell is not facing direct sunlight or heat sources, which can cause false triggers.
App Not Receiving Notifications
- Check your phone’s notification settings for the Ring app.
- Ensure the app is not in “Do Not Disturb” mode.
- Restart your phone and reopen the app.
Final Tips for Long-Term Use
Now that your Ring Doorbell Pro and Chime are installed, here are a few tips to keep everything running smoothly:
- Update the app regularly: Ring frequently releases updates with new features and security improvements.
- Clean the camera lens monthly: Dust and dirt can blur your video feed.
- Check battery levels (if using Chime Pro): The Chime Pro has a backup battery that should last several hours during a power outage.
- Review recordings: Use the Ring Protect Plan to save and review video clips (subscription required).
- Adjust settings seasonally: In winter, reduce motion sensitivity to avoid alerts from snow or ice.
Conclusion
Installing the Ring Doorbell Pro with Chime is a smart upgrade that enhances your home’s security and convenience. With the right tools, a little patience, and this step-by-step guide, you can complete the installation safely and effectively—no electrician required.
From turning off the power and checking your transformer to mounting the doorbell and syncing the Chime, every step is designed to ensure a reliable, high-performance system. Once everything is set up, you’ll enjoy crystal-clear video, instant alerts, and peace of mind knowing your home is protected.
Remember, if you run into any issues, the Ring support team and online community are great resources. And don’t forget to test your system thoroughly before finishing.
Now go enjoy your new smart doorbell—and never miss a visitor again!
