This guide walks you through how to install a Ring Doorbell Wedge Kit to improve your doorbell’s viewing angle and video quality. Whether you’re mounting on brick, siding, or uneven surfaces, we’ll help you get it right the first time—no experience needed.
Key Takeaways
- Improve your Ring Doorbell’s field of view: The wedge kit adjusts the angle to reduce blind spots and capture more of your front yard or walkway.
- Compatible with most Ring models: Works with Ring Video Doorbell, Ring Doorbell 2, 3, 3 Plus, 4, and Pro (check compatibility before buying).
- Easy DIY installation: No special tools required—just a screwdriver, drill (optional), and about 20–30 minutes of your time.
- Secure and weather-resistant: The wedge mounts flush against your wall and protects wiring from moisture and tampering.
- Adjustable angles available: Choose from 5°, 10°, or 15° wedges depending on your mounting surface and desired coverage.
- Use the Ring app for alignment: Live view helps you fine-tune positioning before finalizing the mount.
- Troubleshooting tips included: Fix common issues like loose mounts, poor Wi-Fi signal, or misaligned video.
How to Install Ring Doorbell Wedge Kit: A Complete Step-by-Step Guide
So, you’ve got your Ring Doorbell—great choice! But maybe you’ve noticed that your video feed isn’t quite capturing what you need. Maybe your front walkway is cut off, or the camera is pointing too high or too low. That’s where the Ring Doorbell Wedge Kit comes in. This simple accessory lets you adjust the angle of your doorbell for a better view, fewer blind spots, and clearer footage.
In this guide, we’ll walk you through how to install a Ring Doorbell Wedge Kit from start to finish. Whether you’re mounting on brick, stucco, wood, or vinyl siding, we’ve got you covered. You don’t need to be a handyman—just follow along, and you’ll have your doorbell perfectly angled in under 30 minutes.
By the end of this guide, you’ll know:
– What the wedge kit is and why it’s useful
– Which Ring models are compatible
– How to choose the right wedge angle
– Step-by-step installation instructions
– Tips for optimal placement and alignment
– How to troubleshoot common issues
Let’s get started!
What Is a Ring Doorbell Wedge Kit?
The Ring Doorbell Wedge Kit is an optional mounting accessory designed to tilt your Ring Doorbell forward or backward, improving the camera’s field of view. It’s especially helpful if your doorbell is mounted on a slanted surface, near a corner, or too high/low on the wall.
The kit includes:
– One or more wedge mounts (typically 5°, 10°, or 15° angles)
– Mounting screws
– Wall anchors (for brick, concrete, or other hard surfaces)
– A security screw (to prevent tampering)
The wedge essentially acts as a shim between your wall and the doorbell mount, allowing you to angle the camera downward to capture more of your doorstep, walkway, or driveway.
For example, if your doorbell is mounted high on a brick wall, a 10° or 15° downward wedge can help point the camera toward your front walk instead of the sky. This means you’ll actually see visitors approaching—not just their hats.
Is the Wedge Kit Right for You?
Before you buy or install, ask yourself:
– Is my Ring Doorbell pointing too high or too low?
– Am I missing motion alerts because the camera doesn’t see the walkway?
– Is my doorbell mounted on a slanted or uneven surface?
If you answered “yes” to any of these, the wedge kit is likely a great solution.
It’s also useful if:
– You have a narrow entryway
– Your doorbell is near a corner or recessed area
– You want to reduce glare from sunlight or porch lights
Keep in mind: the wedge kit is not a replacement for proper placement. It enhances your existing setup—it doesn’t fix a doorbell mounted in the wrong spot entirely.
Compatible Ring Doorbell Models
The Ring Doorbell Wedge Kit is compatible with most wired and battery-powered Ring Doorbells, including:
– Ring Video Doorbell (1st gen)
– Ring Doorbell 2
– Ring Doorbell 3
– Ring Doorbell 3 Plus
– Ring Doorbell 4
– Ring Doorbell Pro
– Ring Doorbell Pro 2
It does not work with Ring Doorbell Elite or Ring Intercom systems.
Always double-check compatibility on the Ring website or product packaging before purchasing. Most kits will list supported models clearly.
Choosing the Right Wedge Angle
Ring offers wedge kits in three angles: 5°, 10°, and 15°. The right one depends on your wall and desired camera angle.
Here’s a quick guide:
5° Wedge
Best for minor adjustments. Use if your doorbell is only slightly misaligned—maybe it’s pointing a little too high, but not drastically. Ideal for flat walls with a small overhang or slight slope.
Visual guide about How to Install Ring Doorbell Wedge Kit
Image source: images.ctfassets.net
10° Wedge
The most popular choice. Great for standard mounting on brick, stucco, or siding where the doorbell needs a moderate downward tilt. Captures most of the walkway without cutting off the top of visitors’ heads.
15° Wedge
Use for steep angles or high mounting points. If your doorbell is mounted near the ceiling or on a very slanted surface, this provides the strongest downward tilt. Be careful—too much angle can make people appear distorted or cut off at the top.
Tip: Start with a smaller angle. You can always stack wedges (e.g., 5° + 10° = 15°) if needed, but it’s better to avoid over-angling.
Tools and Materials You’ll Need
You don’t need a full toolbox—just a few basics:
- Phillips-head screwdriver
- Drill (optional, but helpful for hard surfaces like brick)
- Drill bit (matching the size of the wall anchors)
- Pencil or marker
- Level (to ensure straight mounting)
- Measuring tape (optional, for precise placement)
- Smartphone with the Ring app installed
If you’re mounting on brick, concrete, or stucco, you’ll definitely want a drill and the included wall anchors. For wood or vinyl siding, a screwdriver may be enough.
Safety tip: Turn off power at the breaker if you’re installing a wired Ring Doorbell. Even though it runs on low voltage, it’s better to be safe.
Step-by-Step Installation Guide
Now, let’s install your Ring Doorbell Wedge Kit. Follow these steps carefully for a secure, professional-looking mount.
Step 1: Turn Off Power (For Wired Models)
If you’re installing a wired Ring Doorbell (like the Pro or 3 Plus), turn off the power at your home’s circuit breaker. This prevents any risk of electrical shock while handling wires.
Use a non-contact voltage tester to confirm the power is off before touching any wires.
Step 2: Remove Your Existing Doorbell (If Applicable)
If you already have a Ring Doorbell installed, gently remove it from the mount. Most models slide off after loosening the security screw at the bottom.
Unscrew the mounting plate from the wall and disconnect the wires (for wired models). Label the wires (e.g., “Front” and “Trans”) so you can reconnect them correctly later.
Step 3: Choose Your Wedge Angle
Based on your wall and desired camera angle, select the appropriate wedge. If you’re unsure, start with the 10° wedge—it’s the most versatile.
Place the wedge against the wall where you plan to mount it. Hold your phone up to simulate the camera view. Does it look like it will capture the walkway? Adjust as needed.
Step 4: Mark the Mounting Holes
Hold the wedge (with the mounting plate attached) against the wall in the desired position. Use a pencil to mark the screw holes.
Use a level to ensure the wedge is straight. A crooked mount will make your doorbell look tilted, even if the camera angle is correct.
Step 5: Drill Pilot Holes (If Needed)
For hard surfaces like brick or concrete, drill pilot holes using the appropriate drill bit. This prevents cracking and makes screwing easier.
Insert the included wall anchors into the holes. Tap them gently with a hammer until flush with the wall.
For wood or siding, you can often screw directly into the surface without drilling—just be careful not to overtighten.
Step 6: Attach the Wedge and Mounting Plate
Line up the wedge with the marked holes. Secure it to the wall using the provided screws. Tighten firmly, but don’t over-tighten—this can crack the wedge or strip the screw holes.
Make sure the mounting plate is level and secure. Give it a gentle tug to test stability.
Step 7: Reconnect Wires (For Wired Models)
If you’re installing a wired Ring Doorbell, reconnect the wires to the terminals on the back of the doorbell. Match the labels you made earlier.
Most Ring models have color-coded terminals or labels like “Front” and “Trans.” If unsure, refer to the Ring app or installation guide.
Step 8: Attach the Doorbell to the Mount
Slide your Ring Doorbell onto the mounting plate. It should click into place.
Tighten the security screw at the bottom using the included screwdriver or a Phillips-head. This prevents theft and keeps the doorbell secure.
Step 9: Turn Power Back On (For Wired Models)
Restore power at the breaker. Wait a few seconds for the doorbell to boot up.
You should see a light on the front (usually white or blue) indicating it’s receiving power.
Step 10: Use the Ring App to Adjust and Test
Open the Ring app on your smartphone. Go to Devices > select your doorbell > Device Settings > Live View.
Check the camera angle. Is it capturing the walkway? Are people fully in frame? Adjust the wedge if needed—sometimes a small tweak makes a big difference.
Test motion detection by walking in front of the doorbell. Make sure alerts are triggered correctly.
Tips for the Best Results
Want to get the most out of your wedge kit? Here are some pro tips:
- Use the Live View feature: The Ring app’s live feed is your best friend during installation. It lets you see exactly what the camera sees in real time.
- Angle downward, not sideways: The wedge is designed to tilt the camera up or down—not left or right. For side adjustments, reposition the entire mount.
- Avoid extreme angles: A 15° wedge can distort video or cut off the top of people’s heads. Use it only when necessary.
- Check Wi-Fi signal: A weak signal can cause lag or poor video quality. Use the Ring app’s signal strength indicator to ensure your doorbell has a strong connection.
- Clean the lens regularly: Dust, dirt, and spiderwebs can block the camera. Wipe the lens with a soft, dry cloth every few weeks.
- Consider lighting: If your walkway is dark at night, add a porch light or use Ring’s built-in night vision. Avoid pointing the camera directly at bright lights to prevent glare.
Troubleshooting Common Issues
Even with careful installation, you might run into a few hiccups. Here’s how to fix the most common problems.
Problem: Doorbell Won’t Power On
Check the wiring connections. Make sure the wires are securely attached and not loose. For battery models, ensure the battery is charged and properly inserted.
Problem: Video Is Blurry or Out of Focus
Clean the camera lens. If that doesn’t help, check the angle—too steep a wedge can cause distortion. Also, ensure the doorbell isn’t mounted too far from the subject (ideal range is 3–10 feet).
Problem: Motion Alerts Aren’t Triggering
Adjust the motion zones in the Ring app. Make sure the area you want to monitor is included. Also, check that the sensitivity is set appropriately—too low, and it won’t detect movement.
Problem: Doorbell Feels Loose
Tighten the security screw. If the mount itself is wobbly, remove it and check the screws and wall anchors. You may need longer screws or better anchors for your wall type.
Problem: Poor Wi-Fi Signal
Move your router closer or use a Wi-Fi extender. Ring recommends a signal strength of at least -60 dBm for reliable performance. You can check this in the Ring app under Device Health.
Problem: Wedge Looks Crooked
Remove the doorbell and remount the wedge using a level. Even a slight tilt can be noticeable in the video feed.
When to Call a Professional
Most people can install a Ring Doorbell Wedge Kit on their own. But if you’re dealing with:
– Complex wiring (e.g., doorbell transformer issues)
– Historic homes with fragile walls
– High or hard-to-reach mounting locations
– Electrical concerns you’re not comfortable handling
…it’s worth hiring a licensed electrician or handyman. Safety first!
Final Thoughts
Installing a Ring Doorbell Wedge Kit is a simple upgrade that can make a big difference in your home security. By adjusting the camera angle, you’ll capture more of what matters—whether it’s a package delivery, a visitor, or a suspicious loiterer.
The process is straightforward, requires minimal tools, and takes less than half an hour. With the right wedge angle and a little patience, you’ll have a perfectly positioned doorbell that works exactly how you want it to.
Remember: the key to success is planning. Choose the right angle, use the Ring app to test your view, and don’t rush the mounting process. A little care now means fewer headaches later.
So go ahead—grab your wedge kit, follow this guide, and enjoy a clearer, smarter view of your front door.
