This guide walks you through installing a Ring Video Doorbell 2 with an existing Nutone doorbell, covering wiring, mounting, app setup, and troubleshooting. Whether you’re replacing your old chime or keeping it, we’ve got you covered with clear, beginner-friendly instructions.
Key Takeaways
- Compatibility Check: Ensure your Nutone doorbell system supports 8–24V AC and has a mechanical chime (not digital) for best results with Ring Doorbell 2.
- Turn Off Power: Always shut off power at the breaker before handling wires to prevent electrical shock or damage.
- Use the Right Tools: A voltage tester, screwdriver, drill, and wire strippers are essential for a safe and secure installation.
- Mounting Matters: Install the Ring Doorbell at a 15–30 degree angle and 48–60 inches high for optimal motion detection and video quality.
- App Setup is Key: Download the Ring app, create an account, and follow the in-app instructions to connect your device to Wi-Fi and complete setup.
- Troubleshooting Tips: If the doorbell doesn’t ring or video is poor, check voltage, Wi-Fi signal, and chime compatibility.
- Optional Chime Kit: If your Nutone chime isn’t compatible, use the included Ring Chime or Chime Pro for indoor alerts.
How to Install Ring Video Doorbell 2 with Nutone Doorbell
Upgrading your home security with a Ring Video Doorbell 2 is a smart move—especially when you already have a reliable Nutone doorbell system in place. The good news? You don’t have to rip out your existing setup. With a few simple steps, you can integrate the Ring Doorbell 2 with your Nutone chime and enjoy crystal-clear video, two-way talk, and real-time alerts—all from your smartphone.
This guide will walk you through the entire process, from checking compatibility to final testing. Whether you’re a DIY enthusiast or a first-time installer, we’ll keep things simple, safe, and stress-free. By the end, you’ll have a fully functional smart doorbell that works seamlessly with your home’s existing wiring and chime.
Let’s get started!
What You’ll Need Before You Begin
Visual guide about How to Install Ring Video Dooorbell 2 with Nutone Doorbell
Image source: i1.wp.com
Before you touch a single wire, make sure you have all the tools and materials ready. Rushing into the installation without preparation can lead to mistakes, delays, or even electrical hazards.
Here’s your checklist:
- Ring Video Doorbell 2 (obviously!)
- Ring Doorbell mounting bracket (included)
- Phillips and flathead screwdrivers
- Drill and drill bits (for mounting)
- Wire strippers
- Voltage tester (non-contact type recommended)
- Electrical tape
- Screws and anchors (usually included, but extras are helpful)
- Smartphone with the Ring app installed
- Wi-Fi network name and password
- Ladder (if your doorbell is high up)
Pro tip: If your Nutone chime is older or you’re unsure about voltage, consider purchasing a Ring Chime or Chime Pro as a backup. These plug into any outlet and sync with your Ring Doorbell to provide indoor alerts—no wiring needed.
Step 1: Check Compatibility with Your Nutone Doorbell
Not all doorbell systems play nice with smart doorbells. Before you start, it’s crucial to confirm that your Nutone doorbell is compatible with the Ring Video Doorbell 2.
Check Your Chime Type
The Ring Doorbell 2 works best with mechanical chimes—the kind that use physical hammers to strike metal bars. If your Nutone chime is mechanical (you’ll hear a distinct “ding-dong” sound), you’re in good shape.
Avoid installing Ring Doorbell 2 with digital or electronic chimes unless you’re using a Ring Chime. Digital chimes often have built-in circuits that can interfere with the Ring’s power draw, causing it to reboot or fail to ring.
To check:
– Open your Nutone chime cover (usually held by screws).
– Look for physical hammers and metal bars inside.
– If you see circuit boards, LED displays, or no moving parts, it’s likely digital.
Test the Voltage
The Ring Doorbell 2 requires a power supply between 8 and 24 volts AC. Most Nutone systems fall within this range, but it’s best to verify.
Here’s how:
1. Turn off power at the breaker.
2. Remove the front cover of your Nutone chime.
3. Use a non-contact voltage tester to check the wires connected to the “Front” and “Trans” terminals.
4. Turn the power back on and test again to confirm voltage is present.
If your voltage is below 8V, the Ring may not function properly. In that case, you may need a Ring Transformer (sold separately) to boost power.
Check Wi-Fi Signal Strength
Your Ring Doorbell needs a strong Wi-Fi connection to stream video and send alerts. Before installing, stand at your front door with your phone and check the signal strength.
– If your Wi-Fi is weak, consider installing a Wi-Fi extender or upgrading to a mesh network system.
– The Ring Doorbell 2 supports 2.4 GHz networks (not 5 GHz), so make sure your router broadcasts on 2.4 GHz.
Step 2: Turn Off the Power
Safety first! Working with electrical wires can be dangerous if the power is still on.
Locate Your Circuit Breaker
Find the breaker that controls your doorbell circuit. It’s often labeled “Doorbell,” “Chime,” or “Front Door.” If you’re unsure, turn off the main breaker to be safe.
Test the Power
After turning off the breaker, go back to your Nutone chime and use your voltage tester to confirm no electricity is flowing. This step is non-negotiable—don’t skip it.
Label the Wires
Before disconnecting anything, take a photo of the wiring setup. Then, use tape to label the wires:
– “Front” – usually connects to the front doorbell button
– “Trans” – connects to the transformer
– “Rear” – if you have a second doorbell (optional)
This will help you reconnect everything correctly later.
Step 3: Remove the Old Doorbell Button
Now it’s time to take off your existing Nutone doorbell button.
Unscrew the Button
Use a screwdriver to remove the two screws holding the doorbell button to the wall. Gently pull the button away from the wall.
Disconnect the Wires
You’ll see two wires connected to the back of the button. Loosen the screws holding them and carefully pull the wires free.
Pro tip: If the wires are short or frayed, use wire strippers to expose fresh copper (about 1/4 inch). This ensures a solid connection with the Ring Doorbell.
Tuck the Wires Safely
Temporarily tape the wires to the wall or tuck them into the wall cavity to prevent them from falling back in.
Step 4: Install the Ring Mounting Bracket
The Ring Doorbell 2 comes with a mounting bracket that ensures a secure fit and proper angle.
Choose the Right Angle
For best results, install the Ring Doorbell at a 15 to 30-degree angle facing outward. This improves motion detection and reduces glare from the sun.
If your door is flush with the wall, use the included wedge mount to create the right angle.
Mark the Screw Holes
Hold the mounting bracket against the wall where you want to install the doorbell. Use a pencil to mark the screw holes.
Make sure the bracket is level—use a spirit level if needed.
Drill Pilot Holes
Drill small pilot holes into the marked spots. This prevents the wall from cracking, especially if you’re drilling into brick or concrete.
Secure the Bracket
Insert wall anchors if needed (included), then screw the bracket into place using the provided screws.
Double-check that it’s tight and level.
Step 5: Connect the Wires to the Ring Doorbell
Now it’s time to connect your existing Nutone wires to the Ring Doorbell 2.
Prepare the Wires
Strip about 1/4 inch of insulation from the ends of both wires if you haven’t already.
Attach the Wires
The Ring Doorbell 2 has two terminals labeled “Front” and “Trans.” It doesn’t matter which wire goes where—just make sure both are securely connected.
1. Loosen the terminal screws.
2. Insert one wire into each terminal.
3. Tighten the screws firmly.
Don’t overtighten—this can damage the wires or terminals.
Secure the Doorbell to the Bracket
Slide the Ring Doorbell onto the mounting bracket until it clicks into place. You should hear a satisfying snap.
Use the included security screw and screwdriver to lock it in. This prevents theft.
Step 6: Restore Power and Test the Doorbell
Now that everything is connected, it’s time to bring the power back.
Turn the Breaker Back On
Go to your circuit breaker and restore power to the doorbell circuit.
Check for Lights
Look at the Ring Doorbell. You should see a light ring illuminate. It may flash blue or white as it powers up.
If nothing happens, double-check your wiring and breaker.
Test the Chime
Press the button on the Ring Doorbell. Your Nutone chime should ring with a clear “ding-dong.”
If it doesn’t ring:
– Check that the wires are tight.
– Confirm your chime is mechanical.
– Consider using a Ring Chime as an alternative.
Step 7: Set Up the Ring App
The final step is connecting your Ring Doorbell to your smartphone.
Download the Ring App
If you haven’t already, download the Ring app from the Apple App Store or Google Play.
Create or Log In to Your Account
Open the app and either create a new account or log in with your existing credentials.
Add Your Device
Tap the “+” icon and select “Set up a device.” Choose “Doorbells” and then “Ring Video Doorbell 2.”
Follow the on-screen instructions. The app will guide you through:
– Scanning the QR code on the back of the doorbell
– Connecting to your Wi-Fi network
– Naming your doorbell (e.g., “Front Door”)
– Setting up motion zones and alerts
Test Live View and Two-Way Talk
Once connected, tap “Live View” to see the camera feed. Speak into your phone to test two-way audio.
Adjust settings like motion sensitivity, notification preferences, and video quality as needed.
Troubleshooting Common Issues
Even with careful installation, problems can arise. Here’s how to fix the most common ones.
Doorbell Doesn’t Ring the Chime
– Cause: Incompatible chime or low voltage.
– Solution: Use a Ring Chime or upgrade your transformer.
Video is Blurry or Delayed
– Cause: Weak Wi-Fi signal.
– Solution: Move your router closer or add a Wi-Fi extender.
Doorbell Keeps Rebooting
– Cause: Insufficient power.
– Solution: Test voltage and consider a Ring Transformer.
Motion Alerts Are Too Sensitive
– Cause: Motion zones include busy areas (e.g., street).
– Solution: Adjust motion zones in the app to focus on your porch.
Night Vision Isn’t Working
– Cause: Obstructions or dirty lens.
– Solution: Clean the lens with a soft cloth and ensure nothing blocks the infrared LEDs.
Maintenance Tips for Long-Term Performance
To keep your Ring Doorbell 2 running smoothly:
– Clean the lens monthly with a microfiber cloth.
– Check for loose wires or screws every few months.
– Update the Ring app and firmware regularly.
– Replace the rechargeable battery if you’re using the battery-powered model (though the wired version doesn’t need one).
Conclusion
Installing a Ring Video Doorbell 2 with your existing Nutone doorbell is a straightforward process that can significantly boost your home’s security. By following this guide, you’ve successfully replaced your old button, connected the wiring, mounted the device, and set up the app—all while keeping your trusted Nutone chime.
Remember: safety comes first. Always turn off the power, test your voltage, and double-check connections. And if your chime isn’t compatible, don’t worry—the Ring Chime is a great alternative.
Now, enjoy peace of mind knowing you can see, hear, and speak to anyone at your door—from anywhere in the world. Welcome to the future of home security!
