How to Make an IoT Doorbell

Imagine being able to know who’s at your door—even when you’re miles away. With an IoT (Internet of Things) doorbell, you can receive instant notifications on your phone, see who’s visiting, and even interact remotely. Whether you’re a tech enthusiast, a DIY hobbyist, or just someone looking to upgrade home security, building your own IoT doorbell is easier than you think.

In this comprehensive guide, you’ll learn how to make an IoT doorbell from scratch using affordable components, basic electronics knowledge, and a bit of coding. We’ll walk you through selecting the right parts, wiring everything together, writing and uploading code, connecting to the internet, and setting up smartphone notifications. By the end, you’ll have a fully functional smart doorbell that fits your needs and enhances your home’s security.

No prior experience? No problem. This project is beginner-friendly and designed for anyone with curiosity and a willingness to learn. Let’s get started!

Why Build an IoT Doorbell?

How to Make a Iot Doorbell

Visual guide about How to Make a Iot Doorbell

Image source: media.printables.com

Traditional doorbells are simple—press a button, hear a chime. But they don’t tell you who’s there, when they came, or let you respond if you’re not home. An IoT doorbell solves these problems by connecting your doorbell to the internet.

Here are some key benefits:

  • Remote notifications: Get alerts on your phone no matter where you are.
  • Enhanced security: Know when someone approaches your door, even if they don’t ring the bell.
  • Integration with smart home systems: Connect to Alexa, Google Home, or other platforms.
  • Customizable features: Add a camera, microphone, or motion sensor later.
  • Cost-effective: Build it for under $30 using off-the-shelf parts.

Whether you want peace of mind while traveling or just love tinkering with tech, an IoT doorbell is a practical and fun project.

What You’ll Need: Components and Tools

Before we begin, let’s gather all the necessary components and tools. Most of these are inexpensive and widely available online or at electronics stores.

Essential Components

  • Microcontroller: ESP32 or ESP8266 (We recommend the ESP32 for its dual-core processor and Bluetooth support.)
  • Push Button: A momentary switch to act as the doorbell button. You can reuse your existing doorbell button.
  • Resistor: A 10kΩ pull-down resistor to stabilize the button input.
  • Breadboard and Jumper Wires: For prototyping and connecting components.
  • Power Supply: A 5V USB power adapter or your existing doorbell transformer (if it outputs 5V or can be stepped down).
  • Optional – LED: To indicate when the button is pressed.
  • Optional – Buzzer or Speaker: To play a sound locally when the doorbell rings.

Software and Accounts

  • Arduino IDE: Free software to write and upload code to your microcontroller.
  • Wi-Fi Network: Your home Wi-Fi with SSID and password.
  • IFTTT Account: Free service to send smartphone notifications (we’ll use this for alerts).
  • Smartphone: To receive notifications and test the system.

Tools

  • Soldering iron (optional, for permanent builds)
  • Wire strippers
  • Multimeter (helpful for testing connections)
  • Computer with USB port

Step 1: Setting Up Your Development Environment

Before connecting any hardware, we need to prepare your computer to communicate with the ESP32.

Install Arduino IDE

Go to the official Arduino website (arduino.cc) and download the Arduino IDE for your operating system (Windows, Mac, or Linux). Install it like any other application.

Add ESP32 Board Support

The ESP32 isn’t included by default in Arduino IDE, so we need to add it:

  1. Open Arduino IDE.
  2. Go to File > Preferences.
  3. In the “Additional Boards Manager URLs” field, paste this URL:
    https://dl.espressif.com/dl/package_esp32_index.json
  4. Click OK.
  5. Go to Tools > Board > Boards Manager.
  6. Search for “ESP32” and install the “ESP32 by Espressif Systems” package.

Select Your Board

Once installed:

  • Go to Tools > Board and select your ESP32 model (e.g., “ESP32 Dev Module”).
  • Set the correct port under Tools > Port (it usually appears as “COMx” on Windows or “/dev/cu.usbserial” on Mac).

Test with a Simple Blink Program

Let’s make sure everything works:

  1. Open File > Examples > 01.Basics > Blink.
  2. Click the upload button (right arrow).
  3. If the onboard LED blinks, your setup is successful!

Step 2: Wiring the Circuit

Now let’s connect the physical components. We’ll use a breadboard for easy prototyping.

Connect the Push Button

  1. Place the push button on the breadboard.
  2. Connect one side of the button to 3.3V on the ESP32.
  3. Connect the other side to a 10kΩ resistor, then connect the other end of the resistor to GND.
  4. Also connect the same side (with the resistor) to GPIO 4 on the ESP32. This will read the button state.

This setup uses a pull-down resistor to ensure the input pin reads LOW when the button is not pressed and HIGH when it is.

Optional: Add an LED

To visualize when the button is pressed:

  • Connect the anode (long leg) of an LED to GPIO 2 via a 220Ω resistor.
  • Connect the cathode (short leg) to GND.

Power the ESP32

Use a USB cable to connect the ESP32 to your computer for now. Later, you can power it with a 5V wall adapter.

Double-Check Connections

Before uploading code, verify:

  • No loose wires.
  • Correct GPIO pins are used.
  • Resistors are in place to prevent short circuits.

Step 3: Writing the Code

Now we’ll write a program that detects when the button is pressed and sends a notification.

Install Required Libraries

We’ll use the WiFi and HTTPClient libraries (built into Arduino IDE) and connect to IFTTT for notifications.

Create an IFTTT Applet

IFTTT (If This Then That) lets us trigger actions online. Here’s how to set it up:

  1. Go to ifttt.com and create a free account.
  2. Click Create to make a new Applet.
  3. Click “If This” and search for “Webhook”.
  4. Choose “Receive a web request”.
  5. Name the event doorbell_pressed and click Create Trigger.
  6. Click “Then That” and choose “Notifications”.
  7. Select “Send a notification from the IFTTT app”.
  8. Customize the message: “Someone rang the doorbell!”
  9. Click Create Action, then Finish.

Now, go to your IFTTT account settings and find your Webhook key (under Services > Webhook > Documentation). Copy it—we’ll need it in the code.

Write the Arduino Code

Open a new sketch in Arduino IDE and paste the following code. Replace the placeholders with your Wi-Fi and IFTTT details.

#include <WiFi.h>


// Replace with your network credentials

const char* ssid = "YOUR_WIFI_SSID";

const char* password = "YOUR_WIFI_PASSWORD";


// IFTTT Webhook settings

const char* host = "maker.ifttt.com";

const char* event = "doorbell_pressed";

const char* apiKey = "YOUR_IFTTT_KEY"; // From Webhook documentation


// Button pin

const int buttonPin = 4;

const int ledPin = 2;


void setup() {

  Serial.begin(115200);

  pinMode(buttonPin, INPUT);

  pinMode(ledPin, OUTPUT);

  digitalWrite(ledPin, LOW);


  // Connect to Wi-Fi

  WiFi.begin(ssid, password);

  while (WiFi.status() != WL_CONNECTED) {

    delay(500);

    Serial.print(".");

  }

  Serial.println("\nWiFi connected!");

}


void loop() {

  int buttonState = digitalRead(buttonPin);


  if (buttonState
