This guide walks you through how to open Ring Doorbell 1 without damaging the device or voiding your warranty. Whether you’re replacing the battery, cleaning internal components, or troubleshooting, we’ve got you covered with clear, easy-to-follow instructions.

Key Takeaways

Use the right tools: A Phillips #0 or #1 screwdriver and a plastic pry tool are essential for safely opening the Ring Doorbell 1.
Power off before starting: Always remove the battery or disconnect power to avoid electrical shock or short circuits.
Handle cables gently: The internal ribbon cable is delicate—avoid pulling or bending it during disassembly.
Take photos during disassembly: Document each step to make reassembly easier and prevent misplaced screws or components.
Reassemble carefully: Ensure all parts are aligned and screws are tightened properly to maintain weather resistance.
Test after reassembly: Reconnect power and test the doorbell’s functionality through the Ring app before final mounting.
Avoid forcing components: If something doesn’t come apart easily, double-check for hidden screws or clips before applying pressure.

How to Open Ring Doorbell 1: A Complete Step-by-Step Guide

So, you’ve got a Ring Doorbell 1, and for one reason or another, you need to open it up. Maybe the battery is acting up, you want to clean out dust and debris, or you’re troubleshooting a connectivity issue. Whatever the reason, opening your Ring Doorbell 1 might seem intimidating at first—especially if you’re not used to working with small electronics. But don’t worry. With the right tools, a bit of patience, and this detailed guide, you’ll be able to safely access the internals of your device without causing damage.

In this comprehensive how-to guide, we’ll walk you through every step of opening your Ring Doorbell 1. We’ll cover everything from preparing your workspace and gathering the necessary tools to carefully disassembling the unit, handling internal components, and reassembling it properly. You’ll also learn essential safety tips, troubleshooting advice, and best practices to ensure your doorbell works perfectly once it’s back together.

Whether you’re a DIY enthusiast or a first-time tinkerer, this guide is designed to be beginner-friendly while still offering valuable insights for more experienced users. By the end, you’ll feel confident in your ability to open, inspect, and maintain your Ring Doorbell 1 like a pro.

Let’s get started!

Why You Might Need to Open Your Ring Doorbell 1

Visual guide about How to Open Ring Doorbell 1

Image source: i.pinimg.com

Before diving into the disassembly process, it’s helpful to understand the common reasons people open their Ring Doorbell 1. Knowing your goal will help you prepare properly and avoid unnecessary steps.

One of the most frequent reasons is battery replacement. The Ring Doorbell 1 uses a rechargeable lithium-ion battery that typically lasts 6 to 12 months, depending on usage and climate. If your doorbell is frequently losing charge or not turning on, the battery may need replacing. While you can remove the battery without fully opening the unit, accessing the internal compartment sometimes requires partial disassembly.

Another common reason is cleaning or maintenance. Over time, dirt, dust, spiderwebs, and moisture can accumulate inside the doorbell, especially if it’s installed in a high-traffic or outdoor area. Opening the device allows you to gently clean the lens, sensors, and internal components to maintain optimal performance.

Some users open their Ring Doorbell 1 for troubleshooting purposes. If the device is unresponsive, the camera is blurry, or the motion sensor isn’t working, inspecting the internal connections—like the ribbon cable or circuit board—can help identify the issue. In rare cases, water damage or loose wiring may be the culprit.

Lastly, tech-savvy users might open the doorbell to upgrade or modify components, such as installing a custom mount or integrating with other smart home systems. While Ring doesn’t officially support modifications, some users choose to do so at their own risk.

Whatever your reason, always proceed with caution. Opening the device may void your warranty, so check your coverage before starting. If your doorbell is still under warranty and you’re experiencing issues, consider contacting Ring support first.

Tools and Materials You’ll Need

Having the right tools on hand is crucial for a smooth and safe disassembly. Using improper tools can strip screws, crack the casing, or damage internal components. Here’s a list of what you’ll need:

Phillips #0 or #1 screwdriver: The Ring Doorbell 1 uses small Phillips-head screws. A #0 or #1 size is ideal—larger screwdrivers may not fit properly.
Plastic pry tool or spudger: This helps separate the front and back covers without scratching or cracking the plastic. A guitar pick or old credit card can work in a pinch, but a dedicated pry tool is best.
Small container or magnetic mat: Use this to store screws and small parts so they don’t get lost.
Soft cloth or microfiber towel: Place this on your work surface to protect the doorbell from scratches.
Flashlight or good lighting: The screws and components are tiny, so proper lighting is essential.
Optional: Tweezers: Useful for handling small screws or cables.
Optional: Isopropyl alcohol and cotton swabs: For cleaning internal components if needed.

Make sure your workspace is clean, well-lit, and free of static electricity. Working on a wooden or fabric surface is better than metal, which can cause static discharge and damage sensitive electronics.

Step 1: Power Down the Doorbell

Before you begin any physical disassembly, it’s critical to power off the Ring Doorbell 1. This prevents accidental short circuits, electrical shock, or damage to the internal circuitry.

Remove the Battery

The Ring Doorbell 1 is powered by a removable rechargeable battery. To safely power it down:

Locate the battery release button on the bottom of the doorbell. It’s a small, recessed button near the charging port.
Press and hold the button while gently pulling the battery downward. The battery should slide out smoothly.
Set the battery aside in a safe place, preferably in its protective case or on a non-conductive surface.

If your doorbell is hardwired to your home’s electrical system, you should also turn off the power at the circuit breaker. This ensures no electricity is flowing to the device during disassembly. Use a voltage tester to confirm the wires are not live before proceeding.

Wait a Few Minutes

After removing the battery (and turning off the power), wait at least 2–3 minutes before opening the device. This allows any residual charge in the capacitors to dissipate, reducing the risk of electrical damage.

Step 2: Remove the Mounting Bracket (If Installed)

If your Ring Doorbell 1 is still mounted on the wall, you’ll need to remove it before opening the unit. Trying to disassemble it while attached can make the process awkward and increase the risk of dropping or damaging the device.

Unscrew the Mounting Bracket

Locate the two security screws on the bottom of the doorbell. These are designed to prevent theft and require a special tool (usually included with the doorbell) or a small Allen wrench.
Insert the security screwdriver or Allen wrench and turn counterclockwise to loosen the screws.
Once the screws are removed, gently wiggle the doorbell to detach it from the mounting bracket.
Carefully disconnect any wires if your doorbell is hardwired. Take a photo of the wiring setup before disconnecting so you can reconnect it correctly later.

Set the mounting bracket and screws aside. You’ll reattach them after reassembling the doorbell.

Step 3: Open the Ring Doorbell 1 Casing

Now that the doorbell is powered down and removed from the wall, it’s time to open the outer casing. The Ring Doorbell 1 has a two-piece plastic shell held together by screws and plastic clips.

Locate the Screws

Flip the doorbell over so the back is facing up. You’ll see four small Phillips-head screws—two on the top edge and two on the bottom edge. These screws secure the front and back covers together.

Remove the Screws

Using your Phillips #0 or #1 screwdriver, carefully unscrew all four screws.
Place the screws in your small container or magnetic mat to avoid losing them.
Note: The screws are very small and can easily roll away. Work over a towel or tray to catch any that fall.

Separate the Front and Back Covers

Once the screws are removed, the two halves should begin to separate slightly. However, they’re still held together by plastic clips around the edges.

Insert your plastic pry tool into the seam between the front and back covers, starting at the bottom near the charging port.
Gently twist the tool to create a small gap. Work your way around the perimeter, releasing the clips one by one.
Avoid using metal tools or excessive force—this can crack the plastic or damage internal components.
If a section feels stuck, double-check for hidden screws or clips before applying more pressure.

As you separate the covers, you’ll notice a thin ribbon cable connecting the front panel (which includes the camera and motion sensor) to the main circuit board in the back. Do not pull or disconnect this cable yet. We’ll handle it carefully in the next step.

Step 4: Disconnect the Ribbon Cable

The ribbon cable is a flat, flexible wire that transmits power and data between the front and back sections. It’s delicate and easy to damage, so handle it with care.

Locate the Ribbon Cable Connector

On the back cover, you’ll see a small rectangular connector where the ribbon cable plugs into the circuit board. It’s usually held in place by a small plastic latch or flap.

Release the Latch

Use your fingernail or a plastic tool to gently lift the latch on the connector. It should flip up or slide to the side.
Once the latch is open, the ribbon cable should loosen slightly.
Carefully pull the ribbon cable straight out—do not yank or bend it.

If the cable feels stuck, don’t force it. Double-check that the latch is fully open. Forcing the cable can tear it or damage the connector.

Set the Front Cover Aside

With the ribbon cable disconnected, you can now set the front cover (with the camera and sensor) aside. Place it face down on a soft cloth to protect the lens.

Step 5: Access Internal Components

Now that the casing is open and the ribbon cable is disconnected, you have full access to the internal components of your Ring Doorbell 1. This is your opportunity to inspect, clean, or replace parts as needed.

Inspect the Circuit Board

The main circuit board houses the processor, Wi-Fi module, and other critical electronics. Look for signs of damage, such as:

Burn marks or discoloration
Loose or corroded connections
Swollen or leaking capacitors

If you notice any of these issues, it may indicate a hardware failure that requires professional repair or replacement.

Clean the Interior

Over time, dust and debris can accumulate inside the doorbell, especially around the camera lens and motion sensor. To clean:

Use a dry cotton swab to gently wipe the lens and sensor. Avoid touching the lens with your fingers.
For stubborn dirt, lightly dampen the swab with isopropyl alcohol (90% or higher) and wipe carefully. Let it dry completely before reassembly.
Use a can of compressed air to blow out dust from crevices and around the circuit board.

Never use water or cleaning sprays directly on the electronics.

Check the Battery Compartment

Even though you removed the battery earlier, inspect the compartment for corrosion, moisture, or loose contacts. Clean any residue with a dry cloth or alcohol swab.

Step 6: Reassemble the Ring Doorbell 1

Once you’ve completed your inspection, cleaning, or repairs, it’s time to put the doorbell back together. Reassembly is essentially the reverse of disassembly, but it requires attention to detail.

Reconnect the Ribbon Cable

Align the ribbon cable with the connector on the circuit board.
Gently insert the cable until it’s fully seated.
Press the latch down to secure the cable in place. You should hear or feel a slight click.

Double-check that the cable is properly connected and the latch is closed. A loose connection can cause the camera or motion sensor to fail.

Align the Front and Back Covers

Position the front cover over the back, ensuring the ribbon cable isn’t pinched or twisted.
Press the two halves together, starting at the top and working your way down.
Listen for the plastic clips to snap into place.

Reinsert the Screws

Replace the four Phillips-head screws, tightening them evenly but not over-tightening.
Over-tightening can strip the screw holes or crack the plastic.

Step 7: Reinstall the Battery and Test

With the doorbell reassembled, it’s time to restore power and test its functionality.

Reinsert the Battery

Slide the battery back into the compartment until it clicks into place.
Ensure it’s fully seated and secure.

Reconnect Power (If Hardwired)

If your doorbell is hardwired:

Reconnect the wires to the mounting bracket, matching the configuration from your earlier photo.
Turn the power back on at the circuit breaker.
Use a voltage tester to confirm power is restored.

Test the Doorbell

Open the Ring app on your smartphone.
Wait for the doorbell to connect to your Wi-Fi network (this may take a minute).
Test the live view, motion detection, and two-way audio.
Press the doorbell button to ensure it rings and sends a notification.

If everything works correctly, your Ring Doorbell 1 is ready to be remounted.

Troubleshooting Common Issues

Even with careful disassembly and reassembly, you might encounter problems. Here are some common issues and how to fix them:

Doorbell Won’t Power On

Check that the battery is fully charged and properly inserted.
Ensure the ribbon cable is securely connected.
Verify that the power is restored if hardwired.

Camera or Audio Not Working

Inspect the ribbon cable for damage or improper connection.
Clean the camera lens and microphone openings.
Restart the device by removing and reinserting the battery.

Motion Sensor Not Detecting

Ensure the motion sensor lens is clean and unobstructed.
Check the ribbon cable connection.
Adjust motion settings in the Ring app.

Loose or Wobbly Casing

Tighten the four screws evenly.
Ensure all plastic clips are fully engaged.

If problems persist, contact Ring support or consider professional repair.

Safety Tips and Best Practices

To ensure a safe and successful experience when opening your Ring Doorbell 1, keep these tips in mind:

Work in a clean, dry environment: Avoid dusty or humid areas that could damage electronics.
Use anti-static precautions: Touch a grounded metal object before handling internal components to discharge static electricity.
Take photos at each step: This helps you remember how everything fits together during reassembly.
Don’t rush: Take your time, especially when handling small screws and delicate cables.
Keep track of screws: Use a labeled container or magnetic mat to avoid losing them.
Avoid liquids: Never spray water or cleaning solutions directly on the circuit board.

Conclusion

Opening your Ring Doorbell 1 might seem like a daunting task, but with the right preparation and careful execution, it’s entirely manageable. Whether you’re replacing a battery, cleaning internal components, or troubleshooting an issue, this guide has equipped you with the knowledge and confidence to do it safely and effectively.

Remember to always power down the device, use the correct tools, and handle internal components with care. Take your time, document each step, and test thoroughly after reassembly. By following these best practices, you’ll extend the life of your Ring Doorbell 1 and keep it performing at its best.

If you’re ever unsure or uncomfortable with the process, don’t hesitate to seek professional help. But for most users, this DIY approach is a cost-effective and rewarding way to maintain your smart doorbell.

Now that you know how to open Ring Doorbell 1, you’re ready to tackle any maintenance or repair task with confidence. Happy tinkering!
