This guide walks you through how to install the Ring Video Doorbell 2020 release, whether you’re replacing an old doorbell or setting one up for the first time. You’ll learn about wiring, mounting, app setup, and troubleshooting common issues—all in simple, easy-to-follow steps.
Key Takeaways
- Check compatibility first: Ensure your existing doorbell wiring and transformer meet Ring’s requirements (16–24V AC) before installing.
- Use the right tools: A Phillips screwdriver, drill, level, and voltage tester make the installation smoother and safer.
- Mount securely: Choose the correct mounting bracket and angle to maximize your field of view and reduce blind spots.
- Connect to the Ring app: Download the app, create an account, and follow the in-app setup to pair your doorbell with Wi-Fi.
- Test after installation: Always test motion detection, video quality, and notifications to ensure everything works properly.
- Consider a Ring Chime: For louder alerts inside your home, pair your doorbell with a Ring Chime or Chime Pro.
- Maintain regularly: Clean the lens and check battery levels (if using battery mode) every few months for optimal performance.
How to Install Ring Video Doorbell 2020 Release
So, you’ve got your hands on the Ring Video Doorbell 2020 release—congratulations! This smart doorbell offers crisp 1080p HD video, two-way talk, motion detection, and real-time alerts straight to your phone. Whether you’re upgrading from an older model or installing your first smart doorbell, this guide will walk you through every step to get your Ring doorbell up and running smoothly.
By the end of this guide, you’ll know exactly how to install the Ring Video Doorbell 2020 release, from checking your wiring to setting up the app and troubleshooting common issues. We’ll keep things simple, friendly, and practical—no tech jargon overload. Let’s get started!
What’s in the Box?
Visual guide about How to Install Ring Video Doorbell 2020 Release
Image source: img.lazcdn.com
Before you begin, let’s make sure you have everything you need. When you unbox your Ring Video Doorbell 2020 release, you should find:
- The Ring Video Doorbell (2020 model)
- Two interchangeable faceplates (typically Satin Nickel and Venetian Bronze)
- Mounting bracket (angled and flat options)
- Screws and anchors
- Wire nuts
- Security screw and driver
- User manual and quick start guide
If anything is missing, contact Ring customer support right away. It’s also a good idea to download the Ring app on your smartphone before starting—available for both iOS and Android.
Tools You’ll Need
You don’t need to be a professional electrician to install your Ring doorbell, but having the right tools makes the job easier and safer. Here’s what we recommend:
- Phillips head screwdriver
- Drill (with a 3/16” drill bit)
- Level (to keep your doorbell straight)
- Voltage tester (to check if power is off)
- Pliers (optional, for tightening wire nuts)
- Smartphone with the Ring app installed
If you’re installing on brick, stucco, or concrete, you may also need a masonry drill bit and wall anchors.
Step 1: Check Your Existing Doorbell Setup
Before you remove your old doorbell, it’s important to check if your current setup is compatible with the Ring Video Doorbell 2020 release.
Check Your Transformer Voltage
The Ring doorbell requires a transformer that outputs between 16 and 24 volts AC. Most older doorbells use 8–16V, which may not be enough. Here’s how to check:
- Turn off power to your doorbell at the circuit breaker.
- Remove your existing doorbell button from the wall.
- Use a voltage tester to measure the voltage across the two wires.
- If it’s below 16V, you’ll need to upgrade your transformer. Ring sells a compatible transformer, or you can hire an electrician.
Pro Tip: If you’re unsure about your transformer, take a photo of the label and contact Ring support for help.
Check Wire Condition
Inspect the two wires connected to your old doorbell. They should be in good condition—no fraying or corrosion. If they’re damaged, trim them back and strip about 1/4 inch of insulation to expose fresh copper.
Step 2: Turn Off the Power
Safety first! Always turn off the power to your doorbell at the main circuit breaker before working with wires.
Locate Your Circuit Breaker
Most doorbells are on a 15- or 20-amp circuit labeled “doorbell,” “chime,” or “front door.” If you’re not sure, turn off circuits one by one and test your existing doorbell until it stops working.
Double-Check with a Voltage Tester
Even after turning off the breaker, use a non-contact voltage tester to confirm there’s no power running to the wires. Touch the tester to each wire—if it beeps or lights up, the power is still on.
Important: Never work on live wires. If you’re uncomfortable with electrical work, hire a licensed electrician.
Step 3: Remove Your Old Doorbell
Now that the power is off, it’s time to remove your old doorbell.
Unscrew the Old Button
Use your Phillips screwdriver to remove the screws holding the old doorbell to the wall. Gently pull it away from the wall so you can access the wires.
Disconnect the Wires
Loosen the terminal screws or pull the wires out of the back of the old doorbell. Be careful not to let the wires fall back into the wall. You can tape them to the wall temporarily to keep them in place.
Inspect the Mounting Area
Check the condition of the wall where the doorbell was mounted. If there are large holes or damage, you may need to patch them before installing the new doorbell.
Step 4: Choose the Right Mounting Bracket
The Ring Video Doorbell 2020 release comes with two mounting brackets:
- Flat bracket: Use this if your doorbell is flush with the wall.
- Angled bracket (15° or 30°): Use this to adjust the viewing angle, especially if your doorbell is near a corner or walkway.
Determine the Best Angle
Stand back and look at your front door. Where do visitors usually approach? You want the camera to capture people walking up to your door, not just standing directly in front of it.
– Use the 15° bracket for slight adjustments.
– Use the 30° bracket for sharper angles or tight spaces.
Pro Tip: Tape the bracket to the wall first and test the angle with your phone camera to see what the view would look like.
Step 5: Install the Mounting Bracket
Now it’s time to secure the bracket to your wall.
Position the Bracket
Hold the bracket against the wall where you want to install the doorbell. Use a level to make sure it’s straight. Mark the screw holes with a pencil.
Drill Pilot Holes
If you’re mounting into wood or drywall, drill pilot holes slightly smaller than the screws. For brick, stucco, or concrete, use a masonry bit and insert wall anchors.
Secure the Bracket
Line up the bracket with the pilot holes and screw it into place using the provided screws. Make sure it’s tight and doesn’t wiggle.
Step 6: Connect the Wires
Now for the electrical part—don’t worry, it’s simpler than it sounds.
Strip the Wire Ends
If the wire ends aren’t already stripped, use wire strippers to remove about 1/4 inch of insulation from each wire.
Attach Wires to the Doorbell
The Ring doorbell has two terminals labeled “Front” and “Trans.” It doesn’t matter which wire goes where—just connect one wire to each terminal.
– Loosen the terminal screws.
– Wrap the exposed wire around the screw in a clockwise direction.
– Tighten the screw to secure the wire.
Important: Don’t let the bare wires touch each other—this could cause a short circuit.
Use Wire Nuts (Optional)
If your wires are short or you want extra security, you can use the provided wire nuts to connect the doorbell wires to your existing wires. Twist the wires together and screw on the wire nut.
Step 7: Attach the Doorbell to the Bracket
With the wires connected, it’s time to mount the doorbell.
Slide the Doorbell Onto the Bracket
Align the back of the doorbell with the mounting bracket and slide it down until it clicks into place.
Secure with the Security Screw
Use the included security screw and driver to fasten the doorbell to the bracket. This prevents theft and ensures it stays in place.
Attach the Faceplate
Choose your preferred faceplate (Satin Nickel or Venetian Bronze) and snap it onto the front of the doorbell.
Step 8: Turn the Power Back On
Now that everything is connected, restore power at the circuit breaker.
Wait for the Light
The doorbell’s LED light should start blinking blue, indicating it’s powering up and searching for Wi-Fi. This may take a minute or two.
Check for Power Issues
If the light doesn’t turn on:
– Double-check your wiring connections.
– Make sure the transformer is providing enough voltage.
– Try tightening the terminal screws.
Step 9: Set Up the Ring App
The final step is connecting your doorbell to the Ring app.
Download the Ring App
If you haven’t already, download the Ring app from the App Store (iOS) or Google Play (Android).
Create or Log In to Your Account
Open the app and either create a new account or log in with your existing Ring credentials.
Add a New Device
Tap the menu icon (three lines) and select “Set Up a Device.” Choose “Doorbells” and follow the on-screen instructions.
Scan the QR Code
Use your phone’s camera to scan the QR code on the back of your doorbell or inside the app. This pairs the device with your account.
Connect to Wi-Fi
Select your home Wi-Fi network and enter the password. The doorbell will connect to your network.
Complete the Setup
Follow the prompts to name your doorbell (e.g., “Front Door”), set motion zones, and adjust notification settings.
Step 10: Test Your Doorbell
Before you call it a day, make sure everything is working properly.
Test the Video Feed
Open the Ring app and tap on your doorbell to view the live feed. Check for clarity, lighting, and field of view.
Test Two-Way Talk
Press the talk button in the app and speak. Ask someone to stand at the door and confirm they can hear you and respond.
Test Motion Detection
Walk in front of the doorbell to trigger motion alerts. Make sure you receive a notification on your phone.
Test the Doorbell Button
Press the doorbell button. You should hear a chime (if connected to a mechanical chime) and receive a notification.
Troubleshooting Common Issues
Even with careful installation, you might run into a few hiccups. Here’s how to fix the most common problems.
Doorbell Won’t Power On
- Check that the circuit breaker is on.
- Verify the transformer voltage (must be 16–24V AC).
- Ensure wires are securely connected and not touching.
Poor Wi-Fi Connection
- Move your router closer or use a Wi-Fi extender.
- Consider upgrading to a Ring Chime Pro, which boosts Wi-Fi signal.
- Check for interference from other devices.
Blurry or Dark Video
- Clean the lens with a soft, dry cloth.
- Adjust the mounting angle to reduce glare from sunlight.
- Enable “Night Vision” in the app settings.
Motion Alerts Not Working
- Check motion zones in the app—make sure they cover the desired area.
- Adjust sensitivity settings.
- Ensure the doorbell is not facing a busy street or tree (which can cause false alerts).
Chime Not Working
- Verify your mechanical chime is compatible (check Ring’s compatibility list).
- Make sure the “Digital Chime” setting is turned off in the app if using a mechanical chime.
- Try replacing the chime unit if it’s old or faulty.
Tips for Ongoing Maintenance
To keep your Ring Video Doorbell 2020 release working at its best, follow these simple maintenance tips:
- Clean the lens monthly: Use a microfiber cloth to remove dust, dirt, and smudges.
- Check battery level (if applicable): The 2020 model can run on battery, so monitor the charge in the app and recharge when needed.
- Update firmware: The Ring app will notify you when updates are available—install them promptly.
- Review recordings: Periodically check your event history to ensure motion detection is working correctly.
- Adjust settings seasonally: In winter, reduce motion sensitivity to avoid alerts from falling snow or ice.
Conclusion
Installing the Ring Video Doorbell 2020 release is a straightforward process that can significantly enhance your home’s security. By following this guide, you’ve learned how to check compatibility, safely wire your doorbell, mount it correctly, and set it up through the Ring app. You’ve also gained troubleshooting skills to handle common issues and keep your device running smoothly.
Whether you’re a DIY enthusiast or a first-time smart home user, this installation empowers you to monitor your front door from anywhere. With features like live video, two-way talk, and motion alerts, your Ring doorbell is more than just a doorbell—it’s a smart security solution.
Now that you’re all set, enjoy the peace of mind that comes with knowing who’s at your door—even when you’re not home.
